UMI Performance Stage 2 Handling Kits GBF002-2-R

GBF002-2-R is the red-finish edition of UMI's Stage 2 kit, pairing front and rear coil springs with gas-charged monotube shocks, a hollow 1.250" front sway bar, and a solid 1.000" rear sway bar, all matched to red tubular chromoly control arms front and rear. Ride height here is set by the included coil springs rather than adjusted at the shock, so there's no dial-in range to tune after the springs go on.

What's in the kit

Both upper and lower trailing arms are part of the package along with the front control arms, and every bushing included is red polyurethane. UMI supplies all mounting hardware for a bolt-on install that does not call for welding, and the whole package is sold as a complete kit rather than broken into separate purchases.

What to check before buying

Because the lowering amount is baked into the spring rate rather than adjustable afterward, think about the stance you want before ordering rather than planning to fine-tune it once installed. There's no chassis stiffener or trailing arm mount brace called out for this kit, so factor that in if your build needs extra frame rigidity.

Common questions

Can I adjust how low this sits? No, the drop is fixed by the coil springs rather than adjustable afterward.

Are the control arms chromoly or steel? Chromoly, finished red to match the sway bars.
